NX X Design Advanced

NX X Design Advanced builds on the entry-level CAD capabilities of the NX X Design Standard product with a variety of enhancements and additional features to boost design efficiency and quality including re-useable, configurable templates for common features that can drastically reduce design time and reduce duplication of effort. Automated real-time validation, photorealistic rendering and 3D annotation all also allow for improvements throughout the product development process.

NX X Design Advanced also includes base level data management and collaboration capabilities and the tools necessary to integrate with existing Teamcenter data management solutions.

Key features:

Design modeling: Feature-based solid modeling, Synchronous Technology, core Convergent Modeling, drafting, assemblies, basic freeform modeling, user-defined features

Process-specific modeling tools: Sheet metal design, Product and Manufacturing Information (PMI), basic routing

Industrial design: Photorealistic rendering, visualize shape

Product validation: Product validation, HD3D Visual Reporting out-of-the-box (OOTB) report
