Adina Ultimate

ADINA Ultimate includes everything that is in ADINA Advanced, plus ADINA CFD, ADINA FSI, ADINA EM, and ADINA Multiphysics. Choose this software suite to solve your most challenging nonlinear problems involving:

• Geometric, material, and load nonlinearities
• Large deformations
• Contact conditions
• Heat transfer
• Thermo-mechanical coupling
• Computational fluid dynamics
• Fluid structure interaction
• Electromagnetics
• Multiphysics

Create Computational Fluid Dynamic (CFD) Simulations
Model incompressible and compressible flows in a wide array of fluid flows including laminar and turbulent regimes, thin-film Reynolds flow, two-phase flow, non-isothermal flow, conjugate heat transfer, and more. Benefit from material models for handling non-Newtonian fluids and real gasses. Solve flow conditions in arbitrary geometries.

Multiphysics Solution for Complex Fluid-structure Interaction (FSI) Analyses
Use direct FSI coupling or iterative FSI coupling methods to solve the coupling effects of fluids and structures. Satisfy the conditions of displacement compatibility and traction equilibrium. FSI analysis can be performed with incompressible, slightly compressible, low-speed compressible, and high-speed compressible flow. It is ideal for large deformations of soft structures, or highly compressible flows abutting stiff structures. All available element types can be used, including shell, 2D and 3D solid, beam, iso-beam, and contact surfaces, as well as all available material models.

Perform Electromagnetic (EM) Analysis
Electromagnetic effects can be coupled to mechanical or fluid flow systems. Solve for general Maxwell’s equations with different loading and boundary conditions, electrostatic and magnetostatic fields, AC/DC conduction, time-harmonic, eddy current, EM fields with Lorentz forces, EM fields coupled with temperature, and wave guide.

Leverage Unique Breadth and Depth Multiphysics
Gain deeper insight into the performance of designs to understand the consequences of natural phenomena. ADINA Ultimate offers multiphysics capabilities, including FSI, thermo-mechanical coupling (TMC), structural-pore pressure coupling (porous media), thermal-fluid-structural coupling, electric field-structural coupling (piezoelectric), thermal-electrical coupling (Joule heating), acoustic fluid-structural coupling, fluid flow-mass transfer coupling, and fluid flow-electromagnetic coupling.
